Rapco Horizon Y Cable TRS 1/4″-TS 1/4″ Cable

Original price was: $27.95.Current price is: $21.80.

Get the quality you deserve, for less.

Quality Meets Affordability

Multiple payment options for secure shopping with SSL

Safe Shopping Guaranteed

apcoHorizon YS-P Y-cables feature an all metal, hand soldered TRS 1/4″ male connector split wired as in insert to (2) TS 1/4″ Male connectors. Using RHC’s high quality Lo-Z Mic cable lead and RHC shielded INST wire for the legs. All cables individually tested for quality assurance.

able:                                   MIC1.K                                       INST1
Conductor Gauge:                 (2)24 gauge                                  (1)24 gauge
Shield:                                   Bare annealed copper serve          Composite conductive vinyl and copper serve
Shield Coverage:                   95%                                             70%
Jacket:                                   Matte PVC                                  Matte PVC
O.D.                                      0.230″                                         0.242″
Capacitance:                          21 pF/ft. @ 1 kHz                       25 pF/ft. @ 1 kHz
Cond-Shield Capacitance      37 pF/ft. @ 1 kHz
Characteristic Impedance:      70Ω NOMINAL                         60Ω NOMINAL
D.C. Resistance @ 20°C:      23Ω/1000′                                   23Ω/1000′
